WiFi Repeater and WiFi Extender Setup Guide

According to a study by Broadband TV News, 92% of households in the U.S. have internet service.

Among these households:

66% have a smart TV
42% have at least one smart home device
39% have a smart watch
89% have a streaming video service

Given this high level of connectivity, ensuring complete internet coverage throughout your home or business is crucial. This guide will help you improve your WiFi coverage using repeaters and extenders, ensuring a more reliable connection for all your devices.

If you don’t want to do these steps yourself, TekDash can help. One of our expert technicians can set up your home or business with a custom solution for full network coverage. Book our wireless signal extension service now, and we’ll get you connected quickly!

Difference Between WiFi Extender and Repeater

A WiFi extender and a WiFi repeater both serve to expand the coverage area of your WiFi network, but they operate differently.

WiFi Extender

Functionality: Connects to your router via a wired connection or a different WiFi channel and extends the network's reach.
Performance: Provides better performance and reduced interference compared to repeaters.
Setup: Often involves a more detailed configuration process and can offer additional features like guest networks or parental controls.

WiFi Repeater

Functionality: Receives your existing WiFi signal, amplifies it, and then retransmits it on the same channel.
Performance: Can be more prone to interference and signal degradation due to the same channel usage.
Setup: Generally simpler to set up with fewer configuration options.

Extenders typically offer better performance and more features, while repeaters are easier to set up but might have more issues with interference and speed.

What is a WiFi Repeater?

A WiFi repeater, also known as a range extender, is a device that expands the coverage area of your WiFi network. It works by receiving the existing WiFi signal, amplifying it, and then transmitting the boosted signal. This helps get rid of weak spots in your home or office WiFi, making sure you have a strong and reliable connection even in hard-to-reach areas.

Setting up a New WiFi Repeater for Your Home or Business

wifi repeater will extend your network coverage to support connectivity to all your devices.

Setting up a new WiFi repeater is straightforward, even if you're not tech-savvy. Follow these detailed steps:

1. Choose Location: Place the repeater halfway between your router and the area with a weak signal. This ensures it can receive a strong signal to extend.

2. Plug In and Power On: Plug the repeater into an electrical outlet and wait for it to power up. Most repeaters have a power LED that will light up when it’s ready.

3. Connect to the Repeater’s Network: Using a computer, tablet, or smartphone, go to your device’s WiFi settings and connect to the repeater’s default network. This network name (SSID) is usually printed on the repeater or its manual.

4. Access the Setup Page: Open a web browser on your connected device and type in the URL provided in the repeater’s manual (commonly something like "http://192.168.1.1" or "http://extender.setup"). This will take you to the repeater’s configuration page.

5. Login: You may need to enter a username and password. These are often “admin” and “password,” but check your manual for specifics.

6. Follow On-Screen Instructions: The setup wizard will guide you through the process of connecting the repeater to your existing WiFi network. You’ll need to select your home WiFi network and enter the password. Make sure the SSID (network name) and password you enter match your router’s exactly.

7. Relocate the Repeater: Once the setup is complete, move the repeater to a location halfway between the router and the weak signal area if you initially set it up close to the router.

8. Test the Connection: Use your device to check the WiFi signal strength in the previously weak areas. If the connection is strong, the setup is successful. If not, adjust the repeater's location.

By following these steps, you should be able to extend your WiFi coverage and eliminate dead zones in your home or office.

If you'd rather not do these steps yourself, TekDash has you covered and can handle everything for you, book your WiFi repeater setup and working properly!

Netgear WiFi Repeater Setup

To set up a Netgear WiFi repeater using WPS:

Plug the extender near your router and turn it on.
Press the WPS button on the extender and then on your router within two minutes.
Once connected, the extender’s Link Rate LED should light up.
Move the extender to a location halfway between the router and the weak signal area.
Check the connection by ensuring the Link Rate LED stays green or amber.

For more detailed instructions, visit Netgear’s setup guide.

TP Link WiFi Repeater Setup

To set up a TP-Link WiFi repeater:

Plug in the extender near your router.
Connect to the extender's default WiFi network.
Open a web browser and go to "tplinkrepeater.net".
Follow the on-screen instructions to connect the extender to your existing WiFi network.
Move the extender to a location halfway between your router and the weak signal area.

For more details, visit TP-Link’s setup guide.

Linksys WiFi Repeater Setup

To set up the Linksys RE6350 range extender:

Plug the extender into an outlet and wait for the orange light.
Connect to the extender’s default WiFi network, "Linksys Extender Setup."
Enter "extender.linksys.com" or "192.168.1.1" in a browser.
Log in using "admin" as the default password.
Set the SSID and password for both 2.4 GHz and 5 GHz networks.
Apply the changes.

For more detailed instructions, visit Linksys’s support article.

WiFi Repeater FAQs

How do I connect my Wi-Fi repeater to my WiFi?

Follow the Setting up a New WiFi Repeater for Your Home or Business instructions to set this up.

How do I use my NETGEAR router as a WiFi repeater?

You need to enable the repeater mode in the router's settings. This usually involves accessing the router’s configuration page and following specific instructions provided in the manual.

How do I know if my WiFi repeater is connected?

Check the status lights on the repeater. A solid connection light usually indicates a successful connection. You can also test the signal strength in previously weak areas.

What is the best way to use a WiFi repeater?

Place it halfway between your router and the area with weak signal. Ensure it’s in an open space without obstructions.

Why isn't my WiFi repeater working?

Common issues include incorrect setup, interference from other devices, or being placed too far from the router. Refer to the repeater’s manual for troubleshooting steps.

Incorrect Setup:

Placement: Ensure your repeater is placed halfway between your router and the area where you need a stronger signal. If it’s too far from the router, it won’t receive a strong enough signal to extend. Try moving it closer to the router.
Configuration: Double-check that you followed the setup instructions correctly. This usually involves connecting to the repeater’s network, accessing its setup page via a web browser, and entering the correct WiFi network name (SSID) and password.

Interference from Other Devices:

Electronic Devices: Other electronic devices like cordless phones, microwaves, and baby monitors can interfere with your WiFi signal. Try to place your repeater away from such devices.
Neighboring Networks: If you live in a densely populated area, neighboring WiFi networks can cause interference. Use a WiFi analyzer app to check for the best channel to use and change your router’s settings accordingly.

Signal Obstructions:

Physical Barriers: Thick walls, floors, and large metal objects can block or weaken the WiFi signal. Try to place your repeater in an open space with fewer obstructions.

Outdated Firmware:

Update: Check if there are any firmware updates available for your repeater. Manufacturers often release updates to fix bugs and improve performance. Follow the instructions in your repeater’s manual to update the firmware.

Power Issues:

Check Connections: Ensure that your repeater is plugged in and powered on. Sometimes, simply unplugging it and plugging it back in can resolve the issue.

Router Compatibility:

Check Compatibility: Make sure your repeater is compatible with your router. Some older routers may not work well with newer repeaters.

Network Congestion:

Bandwidth Usage: If multiple devices are using the WiFi heavily, it can slow down the network. Try disconnecting some devices to see if the repeater’s performance improves.

Step-by-Step Troubleshooting:

Relocate the Repeater: Move the repeater closer to the router and see if the connection improves.
Reconnect to the Network: Go through the setup process again to ensure all settings are correct.
Minimize Interference: Keep the repeater away from other electronic devices and place it in an open area.
Update Firmware: Check the manufacturer’s website for any available firmware updates and follow the instructions to install them.
Reset the Repeater: As a last resort, reset the repeater to its factory settings and set it up from scratch.

If you’re still having trouble, refer to your repeater’s manual for specific troubleshooting steps, or have one of our expert network technicians solve your issues.

What is a WiFi Extender?

A WiFi extender is similar to a repeater but often provides better performance and more features. It connects to your router and extends the signal to cover larger areas, often creating a seamless network experience.

Setting up a New WiFi Extender for Your Home Or Business

wifi extenders will give you internet coverage in your home and business to have all your devices connected

Setting up a new WiFi extender can seem daunting, but it’s manageable even if you’re not tech-savvy. Follow these detailed steps:

1. Choose Location: Place the extender halfway between your router and the area with weak WiFi signal. This helps ensure it can receive a strong signal from your router to extend.

2. Plug In and Power On: Plug the extender into an electrical outlet and wait for the power LED to light up, indicating it’s ready.

3. Connect to the Extender’s Network: On your computer, tablet, or smartphone, go to the WiFi settings and connect to the extender’s default network. The network name (SSID) and password are usually found on the extender or in its manual.

4. Access the Setup Page: Open a web browser on your connected device and type in the URL provided in the extender’s manual (commonly something like "http://192.168.1.1" or "http://extender.setup"). This will take you to the extender’s configuration page.

5. Login: Enter the default username and password, typically found in the manual. Common defaults are “admin” and “password,” but this can vary.

6. Follow On-Screen Instructions: The setup wizard will guide you through the process of connecting the extender to your existing WiFi network. You’ll need to select your home WiFi network from a list and enter the password. Make sure the SSID (network name) and password you enter match your router’s exactly.

7. Configure Additional Settings (if available): Some extenders offer additional features like guest networks or parental controls. Configure these settings as needed.

8. Relocate the Extender: Once setup is complete, move the extender to a location halfway between your router and the weak signal area if you initially set it up close to the router.

9. Test the Connection: Use your device to check the WiFi signal strength in the previously weak areas. If the connection is strong, the setup is successful. If not, adjust the extender's location.

By following these steps, you should be able to extend your WiFi coverage and eliminate dead zones in your home or office.

If you’d prefer not to handle these steps yourself, TekDash can take care of everything for you. Book and schedule your WiFi Extender setup service now!

Netgear WiFi Extender Setup

Plug in the extender and wait for the Power LED to turn green.
Press the WPS button on the extender and then on your router within two minutes.
Move the extender to a location halfway between the router and the weak signal area.
Check the connection by ensuring the Link Rate LED stays green or amber.

TP Link WiFi Extender Setup

Plug in the extender near your router.
Connect to the extender's default WiFi network.
Open a web browser and go to "tplinkrepeater.net".
Follow the on-screen instructions to connect the extender to your existing WiFi network.
Move the extender to a location halfway between your router and the weak signal area.

Linksys WiFi Extender Setup

Plug the extender into an outlet and wait for the orange light.
Connect to the extender’s default WiFi network, "Linksys Extender Setup."
Enter "extender.linksys.com" or "192.168.1.1" in a browser.
Log in using "admin" as the default password.
Set the SSID and password for both 2.4 GHz and 5 GHz networks.
Apply the changes.

WiFi Extender FAQs

How do I connect a Netgear WiFi extender to my WiFi?

Press the WPS button on the extender and then on your router within two minutes. Check the extender's Link Rate LED for a successful connection. You can follow the instructions above on setting up your netgear wifi extender.

How do I reset my Netgear extender to a new WiFi?

Access the extender’s setup page via a web browser, navigate to the settings, and select the option to reset or change the WiFi network.

Why can't I connect to my Netgear extender?

Ensure you are within range, the extender is properly configured, and there are no interference issues. If you have done all these checks try resetting your Netgear extender to reset the settings and set it up again. Refer to the extender’s manual for troubleshooting.

How to tell if a Netgear WiFi extender is working?

Check the status lights on the extender. A solid connection light indicates it is working. You can also test the signal strength in previously weak areas.

How do I connect my TP-Link to WiFi?

Connect to the TP-Link extender’s default network and access "tplinkrepeater.net" to follow the setup instructions.

How do I access my TP-Link setup?

Enter "tplinkrepeater.net" in a web browser while connected to the extender’s network.

How do I connect my WiFi extender to my router?

Follow the wifi extender setup instructions.

How to reset TP-Link extender to new Wi-Fi?

Access the extender’s setup page and select the option to reset or change the WiFi network settings.

Recommended WiFi Extenders

Buy Now

TP-Link RE605X

Best overall Wi-Fi extender

This powerful extender offers next-gen WiFi 6 technology, providing faster speeds, greater capacity, and reduced network congestion compared to previous WiFi standards. Ideal for large homes or areas with many connected devices, the RE715X ensures seamless streaming, gaming, and browsing experiences.

Key Features:

High-Speed Dual-Band WiFi: Delivers speeds up to 1.8 Gbps with dual-band connectivity (2.4GHz at 574 Mbps and 5GHz at 1201 Mbps), ensuring fast and reliable internet for all your devices.
Wider Coverage: Equipped with high-gain antennas and advanced technology, it extends your WiFi coverage up to 1500 sq. ft., eliminating dead zones in your home.
Seamless Roaming: Supports OneMesh technology, allowing you to create a seamless whole-home network by connecting to a TP-Link OneMesh router. Move around your home without losing connection.
Gigabit Ethernet Port: Provides a wired connection for devices that require a stable and high-speed internet connection, such as smart TVs, gaming consoles, and desktops.
Easy Setup and Management: Use the TP-Link Tether app to set up and manage your network easily. The app provides intuitive tools to monitor signal strength and optimize extender placement.

Dealing with Dead Zones in Your Home or Business

In some homes, WiFi signals have a tough time reaching certain areas, creating frustrating dead zones. Here are some solutions to improve coverage in these areas:

Hard Wiring Access Points

For larger homes and businesses, hard wiring access points can provide a more reliable and robust network solution. By connecting access points directly to your router using Ethernet cables, you can ensure strong and consistent coverage throughout your home or business. This method avoids the potential interference and signal degradation that wireless extenders may face.

Benefits of Hard Wiring Access Points

Stable Connection: Hard-wired access points provide a stable and consistent connection, ideal for high-demand applications like streaming and online gaming.
Better Coverage: By strategically placing wired access points, you can eliminate dead zones and ensure comprehensive coverage.
Increased Speed: Wired connections typically offer faster speeds compared to wireless extenders, which can be affected by distance and interference.

TekDash Ethernet Installation Service

If you’re considering hard wiring access points in your home or business, TekDash offers professional Ethernet installation services. Our team can help design and install a network that meets your specific needs, ensuring optimal coverage and performance.

Book our Ethernet Cable Installation to get your free walkthrough and personalized solution with pricing to improve your network.

Considering a Mesh WiFi Network as an Alternative to a WiFi Extender or WiFi Repeater?

A mesh WiFi network uses multiple nodes to create a seamless and reliable WiFi network throughout your home. It is often more effective than using repeaters or extenders, providing better performance, easier management, and more consistent coverage. Mesh systems automatically manage connections and reduce dead zones more efficiently than traditional extenders.

If you need advise on what is the best solution for you or need a white glove service to get it installed book our Network Setup service now to have one our expert network technician get you up and running properly!

Netgear Orbi Quad-Band WiFi 6E Mesh System

Experience unparalleled WiFi performance with the NETGEAR Orbi Quad-Band WiFi 6E Mesh System. This advanced mesh system is built to give super-fast, reliable, and wide-ranging WiFi coverage for your home or office, making sure all your devices stay connected smoothly.
